Transfer EquipmentAIDA Servo Transfer Unit TCS Series
Advanced motion control enables stable high-speed transferring.
- Equipped with a highly responsive 5-axis servo motor control.
- Optimum Max. SPM ... After the feed length and angle data are set, the Max. SPM under those conditions is operated automatically.
- The TCS Series is highly flexible and can be attached
Capacity Range
Standard lines are available in a range of feed lengths from 150 to 400 mm.
Model | Feed Stroke | Clamp stroke | Lift Stroke | Feedbar Inside Width | Maximum Conveyance weight | Standard Maximum SPM | Maximum Adjustable Feed Stroke | Maximum Adjustable Conveyance Weight | |
---|---|---|---|---|---|---|---|---|---|
(mm) | (mm) | (mm) | Min(mm) | Max(mm) | (kg) | (spm) | (mm) | (kg) | |
TCS-15-20/45 | 0~150 | 0~125 | 0~40 | 200 | 450 | 15 | 110 | 250 | 60 |
TCS-25-30/55 | 0~250 | 0~125 | 0~50 | 300 | 550 | 30 | 90 | 400 | 60 |
TCS-40-35/70 | 0~400 | 0~175 | 0~60 | 350 | 700 | 40 | 75 | 600 | 60 |
TCS-40-45/90 | 0~400 | 0~225 | 0~70 | 450 | 900 | 40 | 60 | 750 | 60 |
